DRS series Technical Datasheet
  •
  • DRS series Technical Datasheet
  •
  •
  • Hall-effect based non-contacting rotary angle sensor
  • Continuous rotating, precise rotary angle measurement
  • Powerful waterproof and protection circuit, compact size
  • CE / FCC / ROHS
  •
  •
  •  DRS series is hall-effect based non-contacting rotary angle sensor to measuring absolute angle degree of a rotating consisting of a concentric rotary sensor and a magnet in 1 set. DRS series are applicable with various equipments and vehicles, medical devices, motors and other rotating bodies.
  • General Specifications

    Item Specification Remark
    Measuring Range 0 ... 360 deg
    0 ... 3,600 deg

    Resolution 0.1 deg
    Accuracy 0.5 deg
    Non-Linearity 1% FS
    Output 0.5 ... 4.5Vdc
    Power Source 10 ... 30VDC
    Current Drain <15mA @12VDC
    Operating Temp. -20 ... +85 celsius
    Waterproof IP68
    Mechanical Life Semi-permanent
    Magnet Ferrite
    Dimensions W48 x D26 x H9mm
    Weight 28g

    • Measuring Range : Infinite rotation from the origin-mark.

    Installation

    • Attach and fix the sensor and magnet to rotating concentrically with center of the rotating.
    • The section of origin-mark of the magnet must be fixed toward + mark of the sensor and the gap between the sensor and the magnet must be within 1mm.
    • There is immeasurable section near zero position as 0 degrees and 360 degrees are same position and moreover output at this point is not continuous.
    • Image shows sensing directions of DRS.



    Data Descriptions

    • Analog Vdc



      • Measuring Range : max range - min range
      • Output V Range : 4.5V - 0.5V = 4V
      • Zero Offset : 0.5V

    • e.g. DRS-10, Output 2.5V,




    Dimensions

    • Refer attached drawings for detail dimensions and size.




    Ordering Code

    • Format : DRS- [1] - [2]

      [1] Model 10
      M10
      0 ... 360 deg range
      0 ... 3,600 deg range
      [2] Direction CW
      CCW
      Clockwise
      Counter-clockwise

      e.g. DRS-10-CW

    • Options
      • Receptacle P/N : MG64REC
      • Cable length : additional cost per meter
      • The plug can be deleted when placed order.

    Wiring Connections

    • DRS series is wired by MG610331-5 plug (Korea Electric Terminal Co., Ltd.). The plug can be deleted when placed order.

    • Color Description
      DRS-10 / M10 RED V+
      BLACK GND (COM)
      GREEN Output+



    NOTES

    • Ground connection is recommended in noise occurred environment.
    • Check installation and sensing directions before use.
    • Check wiring connections before use.
    • 12 months warranty is provided after released. Warranty provided only in case of using for designed purpose correctly.
    • Specifications, design and components can be changed without prior notice to improve its performances.
